Extension-cord wrap on slatwall, holding a wound extension cord

Building…

Extension-cord wrap for slatwall

Not test-printed yetBuilding…

Colours

Puts this design back in its own colours. Designs you haven't coloured show their own colours too, until you pick new ones.

Set your own measurements

Settings

Cord length (m)

The length of the cord you wind on, in metres. 7.5 m = 25 ft, 15 m = 50 ft, 30 m = 100 ft. Sets how far the arms reach. Past about 2 kg of cord the studio warns you to use a steel hook

Cord thickness

Measure across the cord. 18-gauge cords are about 6 mm, 16-gauge about 7 mm, 14-gauge about 8 mm, 12-gauge about 9.5 mm. Sets how far the arms reach and the width of the plug keeper slot

Slats spanned

How many slats the wrap spans, from the top of the upper arm to the bottom of the lower arm (2 slats is about 150 mm on 3 in slatwall). Taller makes longer loops, so the bundle is thinner and the arms shorter. 3 slats is about 280 mm long, so it is for site downloads on a print bed of about 285 mm or more (AI exports come out 2 slats tall)

Arm width

Across the wall. Wider spreads the cord over a broader saddle. 25.4 mm = 1 in, 38.1 mm = 1.5 in, 50.8 mm = 2 in

Latch (optional)

Latch tab (not print-tested)

A tab on the key tip turns up behind the slat, so the hook can't be pulled out

Holds: Extension cord
Kind: Extension-cord wrap
Prints as: One piece
Needs: Nothing to buy

Print settings, already in the 3MF

Worked out from your setup once the part has built.

Extension-cord wrap

Holds: Extension cord

Prints as 1 piece

Holds an extension cord in loops over one arm and under the other, so it won't tangle. Press the end near the plug into the slot in the lower tip to keep it tucked. Set the cord's size, and print in PETG or ASA, not PLA.

CC BY 4.0 · Free

Not test-printed yet. Made with AI and checked against the rules on every wall, but no test print has confirmed it yet.

Walls it fits

VEVOR PVC slatwallFits · some wall sizes assumed · not test-printed yet
StoreWallFits · some wall sizes assumed · not test-printed yet
HandiwallFits · some wall sizes assumed · not test-printed yet
Trusscore SlatWallFits · some wall sizes inferred · not test-printed yet
Retail MDF slatwall, 3 inFits · some wall sizes inferred · not test-printed yet
Flow WallFits · some wall sizes assumed · not test-printed yet
Gladiator GearWallWon't fit: its slot opening is 17 mm, and the hook arm needs a slot opening from 8.5 to 11 mm
ProSlat PVC slatwallWon't fit: ProSlat doesn't publish its slot. Measure your wall and use Custom

History

Updated 14 Oct 2026 0.3.0
First published 8 Oct 2026 0.2.0
