Plier bar for slatwall

Not test-printed yetBuilding…

Colours

Puts this design back in its own colours. Designs you haven't coloured show their own colours too, until you pick new ones.

Set your own measurements

Bar

Pliers

How many bays. With 4 pliers the spacing tops out at 24 mm so the bar stays within the 4 in mount. 4 pliers with an 8 mm bar and 35 mm room behind it is the weakest mix: about 0.8 kg (1.8 lb) per plier, calculated (not tested) for PLA with 2 walls and 15 % infill

Plier spacing

Centre to centre of the bays. Each bay is this less the divider thickness (24 mm apart gives 18.5 mm bays, which suit 6-8 in pliers), 30 mm or more big groove-joint pliers

Bar diameter

Thin enough to slip between the handles just under the hinge

Room behind the bar

Space between the mount and the bar for the back handle

Holds: Pliers
Kind: Plier bar
Prints as: One piece
Needs: Nothing to buy

Print settings, already in the 3MF

Worked out from your setup once the part has built.

Plier bar

Holds: Pliers

Prints as 1 piece

Hangs a row of pliers by the hinge across a round bar, handles down. The back handle drops into its own bay, between dividers that keep the pliers apart. Hang pliers only, one per bay, and print in PETG or ASA, not PLA.

CC BY 4.0 · Free

Not test-printed yet. Made with AI and checked against the rules on every wall, but no test print has confirmed it yet.

Walls it fits

VEVOR PVC slatwallFits · some wall sizes assumed · not test-printed yet
StoreWallFits · some wall sizes assumed · not test-printed yet
HandiwallFits · some wall sizes assumed · not test-printed yet
Trusscore SlatWallFits · some wall sizes inferred · not test-printed yet
Retail MDF slatwall, 3 inFits · some wall sizes inferred · not test-printed yet
Flow WallFits · some wall sizes assumed · not test-printed yet
Gladiator GearWallWon't fit: its slot opening is 17 mm, and the cam-lock mount needs a slot opening from 8.5 to 11 mm
ProSlat PVC slatwallWon't fit: ProSlat doesn't publish its slot. Measure your wall and use Custom

History

First published 8 Oct 2026 1.1.0
