Safety-glasses rack on slatwall, holding a pair of glasses

Building…

Safety-glasses rack for slatwall

Not test-printed yetBuilding…

Colours

Puts this design back in its own colours. Designs you haven't coloured show their own colours too, until you pick new ones.

Set your own measurements

Glasses

Pairs

One to three pairs hang one per tier. Four to six use three tiers, and the top pegs grow longer and thicker to hold a second pair in front of a middle stop

Tier spacing

Peg to peg, top to bottom: your glasses' height from the top of the frame to the bottom of the lens, plus about 8 mm

Holds: Safety glasses
Kind: Safety-glasses rack
Prints as: One piece
Needs: Nothing to buy

Print settings, already in the 3MF

Worked out from your setup once the part has built.

Safety-glasses rack

Holds: Safety glasses

Prints as 1 piece

Holds one to six pairs of safety glasses, folded and hung by the bridge on short pegs. Each peg turns up at the end so a pair can't slide off; with four or more pairs, the top pegs take two each. Print in PETG or ASA, not PLA; it's rated 0.5 kg.

CC BY 4.0 · Free

Not test-printed yet. Made with AI and checked against the rules on every wall, but no test print has confirmed it yet.

Walls it fits

VEVOR PVC slatwallFits · some wall sizes assumed · not test-printed yet
StoreWallFits · some wall sizes assumed · not test-printed yet
HandiwallFits · some wall sizes assumed · not test-printed yet
Trusscore SlatWallFits · some wall sizes inferred · not test-printed yet
Retail MDF slatwall, 3 inFits · some wall sizes inferred · not test-printed yet
Flow WallFits · some wall sizes assumed · not test-printed yet
Gladiator GearWallWon't fit: its slot opening is 17 mm, and the cam-lock mount needs a slot opening from 8.5 to 11 mm
ProSlat PVC slatwallWon't fit: ProSlat doesn't publish its slot. Measure your wall and use Custom

History

First published 8 Oct 2026 1.0.0
