Screwdriver rack on slatwall, holding six screwdrivers

Building…

Screwdriver rack for slatwall

Not test-printed yetBuilding…

Colours

Puts this design back in its own colours. Designs you haven't coloured show their own colours too, until you pick new ones.

Set your own measurements

Rack

Hole count

How many screwdrivers. The rack is this many holes times the spacing wide, up to 240 mm so it fits a 256 mm bed

Hole size (largest shaft)

Diameter of the thickest shaft or bolster that must pass through; every hole is this size, and the handle must be wider than it. Bigger holes leave less bar between them, so the rack holds less

Hole spacing

Centre to centre, a little more than your widest handle: about 22 mm for precision drivers, 30 to 38 mm for full-size ones. Closer holes leave less bar between them: 12 mm holes 20 mm apart hold only about 0.1 kg (0.2 lb), calculated, not tested, for PLA with 2 walls and 15 % infill

Bar depth

How far the bar sticks out from the wall; deeper keeps fat handles off the slat face

Lock

Top wedge lock

Not yet printed. Push the orange button on top of the ledge toward the wall to fill the gap above the arm, so the hook can't lift off. Pull it back out before tipping the hook in or out

Holds: Screwdrivers
Kind: Screwdriver rack
Prints as: One piece
Needs: Nothing to buy

Print settings, already in the 3MF

Worked out from your setup once the part has built.

Screwdriver rack

Holds: Screwdrivers

Prints as 1 piece

Holds screwdrivers in a row of holes, shaft down and handle resting on top. Set the hole count, size and spacing; big holes close together weaken the bar. Hang screwdrivers only and print in PETG or ASA: in PLA the bar is calculated at about 0.45 kg.

CC BY 4.0 · Free

Not test-printed yet. Made with AI and checked against the rules on every wall, but no test print has confirmed it yet.

Walls it fits

VEVOR PVC slatwallFits · some wall sizes assumed · not test-printed yet
StoreWallFits · some wall sizes assumed · not test-printed yet
HandiwallFits · some wall sizes assumed · not test-printed yet
Trusscore SlatWallFits · some wall sizes inferred · not test-printed yet
Retail MDF slatwall, 3 inFits · some wall sizes inferred · not test-printed yet
Flow WallFits · some wall sizes assumed · not test-printed yet
Gladiator GearWallWon't fit: its slot opening is 17 mm, and the cam-lock mount needs a slot opening from 8.5 to 11 mm
ProSlat PVC slatwallWon't fit: ProSlat doesn't publish its slot. Measure your wall and use Custom

History

First published 8 Oct 2026 2.0.0
